Product HighlightsView all

ABLIC Product Highlights

Design Rotation Detection with Greater Freedom for Automotive Motors

The S-57W1/W2 S Series integrates a Hall element capable of detecting magnetic flux density in two different directions on a single chip, allowing it to automatically detect magnetic flux density with a 90° phase difference. The S-57W1/W2 S Series offers a high-sensitivity product with 0.8mT (typ.), enabling reliable detection of weak magnetic flux density. This makes it ideal for motor applications using multi-pole ring magnets with a large number of poles.

Learn more
ABLIC Product Highlights

Design Rotation Detection with Greater Freedom for Compact, Low-profile Motor Applications

The S-5791/92 B Series integrates a Hall element capable of detecting magnetic flux density in two different directions on a single chip, allowing it to automatically detect magnetic flux density with a 90° phase difference. The S-5791/92 B Series offers a high-sensitivity product with 0.8mT (typ.), enabling reliable detection of weak magnetic flux density. This makes it ideal for motor applications using multi-pole ring magnets with a large number of poles.

Learn more
ABLIC Product Highlights

Lower Standby Current in 48V Auxiliary Battery

The S-19230/1 Series delivers the industry’s lowest* current consumption of 2.0 µA typ. This reduces the system’s standby current by efficiently supplying power to continuously operating sensors and other essential components.

Learn more
ABLIC Product Highlights

Building Robust Power Supply Systems

The S-1230/1 Series, featuring an externally set output voltage, is equipped with an open-loop protection circuit. If an open fault occurs in the negative feedback loop, the IC detects the abnormality and prevents the regulator’s output voltage from rising, ontributing to improved system safety.

Learn more
ABLIC Product Highlights

Optimizing Battery-Powered Devices

The S-5719 Series features a wide power supply voltage range from 1.3V to 3.6V. This makes it well-suited for electronic devices powered by typical lithium-ion batteries (approx. 3.0V), as well as those operating at lower voltages, such as silver oxide batteries (approx. 1.55V).

Learn more
ABLIC Product Highlights

Battery Level Indication without MCU

The S-82F9/82D9 Series can light up 5 or 4 LEDs and monitors voltage to provide a simple indication of the remaining battery level. Integrating multiple voltage monitoring functions into a single IC helps save space in systems. Ooperating without a microcontroller reduces power consumption for battery voltage monitoring.

Learn more

NEWS & TOPICSLatest NewsView all

ApplicationsView all

Automotive

Medical

Industrial

Home / Personal

AboutView all

About ABLIC Inc.
ABLIC Inc. started analogue semiconductor business based on the development of CMOS ICs for the world’s first practical quartz watches in 1968.
Since then, we have been continuing to provide small, low-power consumption, and high-precision analog semiconductor products, not only for watches, but also for a wide range of consumer, mobile, automotive devices, and healthcare equipment.
We joined as one of the MinebeaMitsumi Group companies in April 2020, and will keep contributing to the enrichment lives around the world under our vision of inspiring customers with “Small, Smart, Simple” analog semiconductor solutions.
