1. Overview

Generally, in housing and industrial equipment, input AC power is converted to 24V or 12V DC power by AC/DC converters. In order to run motors, sensors, MCUs, etc., products that can operate on the 24V/12V power supply system is a requirement.
We have an extensive lineup of products with high maximum operating voltages. These include linear regulators operating at 50V, switching regulators, voltage detectors and operational amplifiers operating at 36V, Hall ICs operating at 26V, and the S-812C Series(the de facto standard linear regulator, operating at 16V). In addition, we also offer products with a guaranteed high-temperature operation, which is essential for industrial equipment.
Additionally, due to the rise in integration with the IoT, wireless communications are increasingly being used in sensors and security devices within factories as well as within private housing. Since wireless communication devices are battery-powered, it is imperative that battery life must be long-lasting. We achieve this by reaching low-power consumption in our products. Starting from the development of analog semiconductors for quartz watches, we offer a wide range of low-power consumption products.
ABLIC offers semiconductors with high-withstand voltage and low-power consumption that are ideal for housing and industrial equipment.

2. Block Circuit

  • General Housing & Industrial Equipment
  • Wireless Communication Device

ICs ideal for Housing & Industrial Equipment

General Housing & Industrial Equipment

Click the product name for more product information.

Backup Battery 1.8V 5V 24V / 12V Transceiver Pressure Sensor/ Gas Sensor/ etc. MCU AC/DC Motor AC Motor Inverter Driver, OPAMP VD LDO DC-DC Converter or RTC LDO EEPROM WDT VD VD OPAMP Hall effect IC Hall effect IC Hall effect IC LDO

*VD: Voltage detector (Reset IC)   *LDO: Low-dropout regulator   *WDT: Watchdog timer   *RTC: Real-time clock

3. ICs Ideal for Housing & Industrial Equipment

General Housing & Industrial Equipment -Power Management ICs
Product Recommended product Applications and Features
LDO Regulator
(Linear Regulator)
S-812C 16V input, 75mA output. Super low current consumption of 1.0µA, Output Capacitor-less. De facto standard.
LDO Regulator
(Linear Regulator)
S-1312
LDO Regulator
(Linear Regulator)
S-1313
LDO Regulator
(Linear Regulator)
S-1222B/D 28V input, 200mA output. 0.33mm low-profile package.
LDO Regulator
(Linear Regulator)
S-1212/3/4
LDO Regulator
(Linear Regulator)
S-1142C/D
DC-DC converter
(Switching regulator)
S-8580/1 36V input, 600mA output. Output voltage 2.5 to 30.0V. Available in an ultra compact (2.46 x 1.96mm) package.
Voltage Detector
(Reset IC)
S-1000 5.5V operation. Detection voltage 1.5 to 4.6V. High-accuracy detection voltage ±1.0%. Super low current consumption of 0.35µA.
Voltage Detector
(Reset IC)
S-1009 10V operation. Detection voltage 0.8 to 4.6V. High-accuracy detection voltage ±0.5%. Super low current consumption of 0.27µA. External delay time setting.
Voltage Detector
(Reset IC)
S-808xxC 10V operation. Detection voltage 0.8 to 6.0V. Detection voltage accuracy of ±2.0%. Low current consumption of 0.8µA. De facto standard.
Voltage Detector
(Reset IC)
S-809xxC 10V operation. Detection voltage 1.3 to 6.0V. Detection voltage accuracy of ±2.0%. Low current consumption of 1.1µA. External delay time setting. De facto standard.
Voltage Detector
(Reset IC)
S-1002
Voltage Detector
(Reset IC)
S-1003 With manual reset function. 10V operation. Detection voltage 1.2 to 5.0V. High-accuracy detection voltage ±1.0%. Super low current consumption of 0.5µA. External delay time setting.
Voltage Detector
(Reset IC)
S-1011 High-withstand voltage of 36V. Detection voltage 3.0 to 10.0V (0.05V step). Detection voltage accuracy of ±1.5%. Low current consumption of 0.6µA. External delay time setting. SENSE detection.
Watchdog Timer S-1410/1 Industryʼs top class super low current consumption of 3.8µA. With reset function. Available in 2.0 x 3.0mm package. 105℃ operation.
General Housing & Industrial Equipment -Sensor ICs, Amplifiers, Memory ICs, Timer ICs
Product Recommended product Applications and Features
Hall effect IC
(Magnetic sensor IC)
S-576Z B ZCL™ Hall effect ICs are perfect for BLDC motor control, creating stable BLDC motor control over a wide temperature range.
Hall effect IC
(Magnetic sensor IC)
S-576B B Bipolar Hall effect latch ICs are perfect for position and rotation detection and an ultra-thin package contributes to thinner motors.
Operational amplifier S-89713 Capable of detecting high-accuracy current and minute sensor signals. 5.5V operation. Rail-to-Rail input/output. Low offset voltage of 10μV.
Operational amplifier S-89630A High-accuracy current detection and minute sensor signals can be detected. 36V operation. Rail-to-Rail input/output. Low offset voltage of 50μV. 125℃ operation.
EEPROM S-24Cxxx 2-wire Serial EEPROM. Built-in data protection functions. Data can be rewritten up to 1 million.
Real-Time Clock S-35390A Backup of clock function. Current consumption of 0.25µA.
Wireless Communication Device

Click the product name for more product information.

Primary Battery Transceiver MCU CR 17450 3.0V Hall effect IC LDO DC-DC Converter or EEPROM VD Comparator OPAMP Temperature sensor IC Hall effect IC

*VD: Voltage detector (Reset IC)   *LDO: Low-dropout regulator   *RTC: Real-time clock

3. ICs Ideal for Housing & Industrial Equipment

Wireless Communication Device -Power Management ICs
Product Recommended product Applications and Features
LDO Regulator
(Linear Regulator)
S-1318 5.5V input, 100mA output. Ultra-low current consumption of 95nA. Available in an ultra compact (1.0 x 1.0mm) package.
LDO Regulator
(Linear Regulator)
S-1313
LDO Regulator
(Linear Regulator)
S-1206 6.5V input, 250mA output. Super low current consumption of 1.0µA.
DC-DC converter
(Switching regulator)
S-8353/4 10V input, 300mA output. Output voltage 2.0 to 6.5V. Step-up type.
Voltage Detector
(Reset IC)
S-1000 5.5V operation. Detection voltage 1.5 to 4.6V. High-accuracy detection voltage ±1.0%. Super low current consumption of 0.35µA.
Voltage Detector
(Reset IC)
S-1009 10V operation. Detection voltage 0.8 to 4.6V. High-accuracy detection voltage ±0.5%. Super low current consumption of 0.27µA. External delay time setting.
Voltage Detector
(Reset IC)
S-808xxC 10V operation. Detection voltage 0.8 to 6.0V. Detection voltage accuracy of ±2.0%. Low current consumption of 0.8µA. De facto standard.
Voltage Detector
(Reset IC)
S-809xxC 10V operation. Detection voltage 1.3 to 6.0V. Detection voltage accuracy of ±2.0%. Low current consumption of 1.1µA. External delay time setting. De facto standard.
Voltage Detector
(Reset IC)
S-1002
Voltage Detector
(Reset IC)
S-1003 With manual reset function. 10V operation. Detection voltage 1.2 to 5.0V. High-accuracy detection voltage ±1.0%. Super low current consumption of 0.5µA. External delay time setting.
Wireless Communication Device -Sensor ICs, Amplifiers, Memory ICs
Product Recommended product Applications and Features
Hall effect IC
(Magnetic sensor IC)
S-5712x
Temperature Sensor IC S-58LM20A Outputs linear voltage against the temperature change. -50 to 130℃ operation. No need for parts such as resistors and operational amplifiers compared to thermistor configurations.
Operational amplifier S-89430/1 Super low current consumption of 0.5µA. Low voltage operation 0.9 to 5.5V. Operational amplifiers perfect for amplifying sensor signals.
Operational amplifier S-89713 Capable of detecting high-accuracy current and minute sensor signals. 5.5V operation, Rail-to-Rail input/output, low offset voltage of 10μV.
Comparator S-89530/1 Super low current consumption of 0.7µA. Low voltage operation 0.9 to 5.5V. Comparators perfect for detecting sensor signals.
EEPROM S-24Cxxx 2-wire Serial EEPROM. Built-in data protection functions. Data can be rewritten up to 1 million.

4. Features

LDO Regulator S-1318 series
Ultra-low current consumption
Ultra-compact package

5.5 V Input, 100 mA, 95 nA Super Low Current Consumption Voltage Regulator S-1318 Series

Contributes to saving power in battery-powered IoT devices!

This regulator features an operating current of 95nA typ., for ultra-low power consumption to significantly extend battery life.

Series name


S-1318

Datasheet

 5.5V input, 100mA output.

Buy Online


chip1stop corestaFF ONLINE Digi-Key MOUSER

DC-DC converter S-8580/1 series
High-withstand voltage
High-efficiency
Low noise

36V Input, 600 mA Synchronous Step-Down Switching Regulator S-8580/1 Series

Reduces the footprint of a switching regulator

36V(Absolute Maximum Ratings 45V) input and synchronous rectification switching regulator (DC-DC converter) adopt the ultra-small package HSNT-6 (2.46mm x 1.96mm ). Suitable for industrial equipment, house facilities and house appliance, the S-8580/1 contributes to downsize the machines or modules.

>>Learning more about the S-8580/1

Series name


S-8580AA/B,
S-8581AA/B

Datasheet

S-8580AC/D,
S-8581AC/D

Datasheet

Buy Online


chip1stop corestaFF ONLINE Digi-Key MOUSER

Hall Effect IC S-576Z B series
High-temperature operation
ZCL Detection
Thin package

125°C Operation High-Withstand Voltage, High-Speed, ZCL™ Hall Effect IC S-576Z B Series

The ZCL™ Hall Effect ICs transform the brushless DC motor market

A ZCL (Zero Crossing Latch) Hall effect IC, is a latch type Hall effect IC that uses a world's first detection method, by detecting the output signal at the zero-crossing point where polarity changes. It is ideal for BLDC motor control, and unlike other Hall effect ICs, it is not thrown off by variations in magnetic flux density, and can maintain stable detection.

>>Learning more about the S-576Z B

Series name


S-576Z B

Datasheet

 Power supply voltage range: 2.7V ~ 26.0V
 Thin package: TSOT-23-3S (t0.8mm max)
 Ultra-thin package: HSNT-6(2025) (t0.5mm max)

Buy Online


chip1stop corestaFF ONLINE Digi-Key MOUSER

High-accuracy Operational Amplifier S-89630A series
Low offset voltage
36V operation

125°C operation Low Input Offset Voltage CMOS Operational Amplifier S-89630A Series

Contributing to High-Accuracy Current Sensors

A wide operating voltage range allows use of this IC in systems from 5V to high-voltage systems. Low offset voltage enables high-accuracy current detection. Input Rail-to-Rail enables low-side and high-side current detection.

>>Learning more about the S-89630A

Series name


S-89630A

Datasheet

 Operating voltage range: 4.0V to 36V
 Low offset voltage: 50μV max.
 Rail-to-Rail input and output

Buy Online


chip1stop corestaFF ONLINE Digi-Key MOUSER

EEPROM S-24Cxxx series
High reliability
WLP package

EEPROM S-24Cxxx Series

We offer a wide range of product lineups with high reliability, high performance, and high quality

ABLIC's serial EEPROMs offer a wide range of product lineups that supports various interfaces, memory capacity, and packages.

Series name


S-24C02/04/08/16 DS-24Cxx D

Datasheet

 Memory capacity: 2K, 4K, 8K, 16K-bit
 WLP package: 8K-bit , 16K-bit

S-24C32C/64C HS-24CxxC H

Datasheet

 Memory capacity: 32K, 64K-bit

S-24C128C

Datasheet

 Memory capacity: 128K-bit

S-24C256C

Datasheet

 Memory capacity: 256K-bit

S-24C512C

Datasheet

 Memory capacity: 512K-bit

S-24CM01C

Datasheet

 Memory capacity: 1024K-bit
