ICs ideal for ADAS Domain Controllers
Overview
An ADAS Domain Controller is a high-performance Electronic Control Unit (ECU) designed to centralize and manage processing related to Advanced Driver-Assistance Systems (ADAS) and Autonomous Driving (AD). It integrates information from multiple sensors, such as cameras, LiDAR, and radar, to accurately perceive the vehicle's surroundings in real time. This information enables advanced driver-assistance and autonomous driving functions.
ABLIC offers ICs ideal for ADAS Domain Controllers. ABLIC provides a comprehensive product lineup, including shunt voltage references that generate the high-precision reference voltages required for sensor reading, watchdog timers that monitor MCUs with built-in VD, and connection diagnosis ICs for supplying power to GNSS antenna amplifiers.
ICs ideal for ADAS Domain Controllers
Block Circuit
Click the product name for more product information.
*VD: Voltage detector (Reset IC) *LDO: Low-dropout regulator *WDT: Watchdog timer
ICs ideal for ADAS Domain Controllers
ICs ideal for ADAS Domain Controllers
| Product | Recommended product | Datasheet | Applications and Features |
|---|---|---|---|
| Shunt Voltage Reference | S-19760 | The industry's highest output voltage accuracy of ±0.1%. The industry's lowest output voltage temperature coefficient of 20ppm/°C. Maximum shunt current of 15mA. | |
| Shunt Voltage Reference | S-19761 | The industry's highest output voltage accuracy of ±0.1%. The industry's lowest output voltage temperature coefficient of 20ppm/°C. Maximum shunt current of 30mA. | |
| Watchdog Timer | S-19400/1 | Industryʼs top class super-low current consumption 3.8µA. With reset function. Available in 2.0 x 3.0mm package. | |
| Window Voltage Detector | S-191A | 6V operation. Monitors undervoltage and overvoltage. Voltage detection response time of 10µs typ. With manual reset function. | |
| Window Voltage Detector | S-191B | 6V operation. Monitors undervoltage and overvoltage. Voltage detection response time of 10µs typ. | |
| Battery Monitoring IC (Voltage detector) | S-19116 | Fast detection response of 6.8µs max. Overvoltage Detection. Built-in SENSE Pin reverse connection protection circuit. Low current consumption of 2.0µA. | |
| Battery Monitoring IC (Voltage detector) | S-19114 | Fast detection response of 10µs max. Undervoltage Detection. Built-in SENSE Pin reverse connection protection circuit. Low current consumption of 2.0µA. | |
| Battery Monitoring IC (Voltage detector) | S-19110 | Undervoltage Detection. Low current consumption of 0.6μA. | |
| LDO Regulator (Linear Regulator) | S-19259 | 5.5V input, 1000mA. Built-in an inrush current limit circuit. | |
| LDO Regulator (Linear Regulator) | S-19255 | 5.5V input, 300mA, PSRR 80dB. Available in an ultra compact (1.0 x 1.0mm) package. 0.1μF input capacitors can be used. | |
| LDO Regulator (Linear Regulator) | S-19244 | 10V input, 1000mA. Built-in Soft-start function. | |
| LDO Regulator (Linear Regulator) | S-19243 | 10V input, 500mA. Built-in Soft-start function. | |
| LDO Regulator (Linear Regulator) | S-19222 | 36V input, 300mA, 1.8V to 30V output. High PSRR 75dB (at f = 1.0 kHz). Fast Transient Response. 0.1µF input capacitor available. | |
| LDO Regulator (Linear Regulator) | S-19212 | 36V input, 250mA, 2.5V to 16V output. Low current consumption of 6.5µA typ. | |
| LDO Regulator (Linear Regulator) | S-19214 | 36V input, 1000mA, 1.8V to 30V output. Low current consumption of 5.0µA typ. | |
| LDO Regulator (Linear Regulator) | S-19213 | 36V input, 500mA, 1.8V to 30V output. Low current consumption of 5.0µA typ. | |
| LDO Regulator (Linear Regulator) | S-19218 | 36V input, 500mA, 2.5V to 30V output. Fast transient response. | |
| LDO Regulator with a current monitor function | S-19701 | 36V input, 600mA. Used for diagnosing camera connections. An LDO regulator IC capable of detecting a variety of connection faults. | |
| LDO Regulator with a current monitor function | S-19700 | 36V input, 400mA. Used for diagnosing camera connections. An LDO regulator IC capable of detecting a variety of connection faults. | |
| High side switch with a current monitor function | S-19683 | 36V input, 600mA. Used for diagnosing camera connections. Available in 2.0 x 3.0mm package. | |
| High side switch with a current monitor function | S-19680 | Used for diagnosing GNSS antenna connections. Detects short and open circuits and can output alarm signals. | |
| Serial EEPROM | S-25C010A/020A/040A H | SPI, 1K/2K/4K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-25C080A0H | SPI, 8K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-25C160A0H | SPI, 16K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-25C320A/640A H | SPI, 32K/64K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-25C128A0H | SPI, 128K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-93C46C/56C/66C/76C/86C H | 3-wire, 1K/2K/4K/16K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-24C08C H | 2-wire, 8K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-24C16C H | 2-wire, 16K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-24C32C/64C H | 2-wire, 32/64K-bit. Built-in data protection functions. 105°C max. operation. | |
| Serial EEPROM | S-24C128C H | 2-wire, 128K-bit. Built-in data protection functions. 105°C max. operation. |
