Accelerating Advancement of Industrial Equipment
The S-8564/5 Series delivers a 1A output, enabling devices to achieve greater functionality and higher performance. With a 36V input (absolute maximum rating of 45V) and a synchronous rectification switching regulator (DC-DC converter), it features the industry’s smallest* HSNT-8(2030) package (3.0 × 2.0 × t0.5 (max.) mm).
Learn more
Further Miniaturizing Camera Modules
The S-19560B Series is a compact 3-channel PMIC that integrates two buck DC-DC converters and one LDO regulator in a space-saving HSNT-8(2030) package (3.0 × 2.0 × t0.5mm).
Learn more
Wireless. Batteryless. Revolutionary leak detection.
CLEAN-Boost™ technology uses microwatt energy sources to autonomously generate electricity from leaking water and transmit water leak signals wirelessly. Batteryless operation provides flexible layout for installation.
Learn more
Design Rotation Detection with Greater Freedom for Automotive Motors
The S-57W1/W2 S Series integrates a Hall element capable of detecting magnetic flux density in two different directions on a single chip, allowing it to automatically detect magnetic flux density with a 90° phase difference. The S-57W1/W2 S Series offers a high-sensitivity product with 0.8mT (typ.), enabling reliable detection of weak magnetic flux density. This makes it ideal for motor applications using multi-pole ring magnets with a large number of poles.
Learn more
Design Rotation Detection with Greater Freedom for Compact, Low-profile Motor Applications
The S-5791/92 B Series integrates a Hall element capable of detecting magnetic flux density in two different directions on a single chip, allowing it to automatically detect magnetic flux density with a 90° phase difference. The S-5791/92 B Series offers a high-sensitivity product with 0.8mT (typ.), enabling reliable detection of weak magnetic flux density. This makes it ideal for motor applications using multi-pole ring magnets with a large number of poles.
Learn more
Lower Standby Current in 48V Auxiliary Battery
The S-19230/1 Series delivers the industry’s lowest* current consumption of 2.0 µA typ. This reduces the system’s standby current by efficiently supplying power to continuously operating sensors and other essential components.
Learn more
S-8564A/8564B/8565A/8565B
36 V Input, 1 A, Low EMI, Synchronous Step-Down Switching Regulator (Buck DC-DC Converter) S-8564A/8564B/8565A/8565B Series
S-8594A/8594B/8595A/8595B
18 V Input, 1 A, Synchronous Step-Down Switching Regulator (Buck DC-DC Converter) S-8594A/8594B/8595A/8595B Series
S-8584A/8584B/8585A/8585B
36 V Input, 1 A, Synchronous Step-Down Switching Regulator (Buck DC-DC Converter) S-8584A/8584B/8585A/8585B Series
S-8560A/8560B/8561A/8561B
36 V Input, 600 mA, Low EMI, Synchronous Step-Down Switching Regulator (Buck DC-DC Converter) S-8560A/8560B/8561A/8561B Series
S-19560B
Automotive, 125°C Operation, 16 V Input, 3 Channel Output, Compact PMIC For Camera Modules S-19560B Series
ABLIC Launches Power Management IC for Automotive Cameras with the Industry's Smallest Mounting Area
ABLIC Launches the S-57W1/W2 Series of Automotive 2D Dual Hall Effect Latch IC
ABLIC Launches Automotive High-Withstand Voltage LDO Linear Regulator IC for 48V Auxiliary Batteries
ABLIC Conducts Semiconductor Outreach Lecture at Yamagata University
About ABLIC Inc.
ABLIC Inc. started analogue semiconductor business based on the development of CMOS ICs for the world’s first practical quartz watches in 1968.
Since then, we have been continuing to provide small, low-power consumption, and high-precision analog semiconductor products, not only for watches, but also for a wide range of consumer, mobile, automotive devices, and healthcare equipment.
We joined as one of the MinebeaMitsumi Group companies in April 2020, and will keep contributing to the enrichment lives around the world under our vision of inspiring customers with “Small, Smart, Simple” analog semiconductor solutions.
