125°C Operation High-Withstand Voltage, High-Speed, ZCL™ Hall Effect IC S-576Z B Series

DatasheetNov. 18, 2019

Web Shop (Online Samples)

Please contact each Web shop for details such as availability of online samples.

English for China, Hong Kong, Taiwan

a New Detection Methodology which turns a new page in brushless DC motor development

This IC, developed by CMOS technology, is a high-accuracy Hall effect IC that operates with high temperature and high-withstand voltage.
The IC switches output voltage level when the IC detects magnetic flux density (magnetic field) polarity changes. The ZCL (Zero Crossing Latch) detection method realizes polarity changes detection with the higher accuracy than the conventional bipolar latch method. Using this IC with a magnet makes it possible to detect the rotation status in various devices.
ABLIC Inc. offers a “magnetic simulation service” that provides the ideal combination of magnets and our Hall effect ICs for customer systems. Our magnetic simulation service will reduce prototype production, development period and development costs. In addition, it will contribute to optimization of parts to realize high cost performance.
For more information regarding our magnetic simulation service, contact our sales representatives.

Features

  • Uses a thin (t0.80 mm max.) TSOT-23-3S or ultra-thin (t0.50 mm max.) HSNT-6(2025) (under development) package, allowing for device miniaturization
  • Contributes to reduction of mechanism operation dispersion through high accuracy detection of magnetic flux density (magnetic field) polarity changes
  • Contributes to device safe design with a built-in output current limit circuit

Specifications

Pole detection
ZCL detection
Output logic*1
VOUT = “L” at S pole detection
VOUT = “H” at S pole detection
Output form*1
Nch open-drain output
Nch driver + built-in pull-up resistor (1.2 kΩ typ.)
Zero crossing latch point
BZ = 0.0 mT typ.
Release point (S pole)*1
BRS = 3.0 mT typ.
BRS = 6.0 mT typ.
Chopping frequency
fC = 500 kHz typ.
Output delay time
tD = 8.0 μs typ.
Power supply voltage range*2
VDD = 2.7 V to 26.0 V
Built-in regulator
Built-in output current limit circuit
Operation temperature range
Ta = −40°C to +125°C
Lead-free (Sn 100%), halogen-free

*1. The option can be selected.
*2. VDD = 2.7 V to 5.5 V when output form is Nch driver + built-in pull-up resistor (1.2 kΩ typ.)

Applications

  • Brushless DC (BLDC) motor
  • Home appliance
  • Housing equipment
  • Industrial equipment
