This IC, developed by CMOS technology, is a high-accuracy Hall effect switch IC that operates with high temperature and high-withstand voltage.
The output voltage level changes when this IC detects the intensity level of magnetic flux density. Using this IC with a magnet makes it possible to detect the open / close in various devices.

Magnetic simulation service
ABLIC Inc. offers a “magnetic simulation service” that provides the ideal combination of magnets and our magnetic sensor ICs for customer systems. Our magnetic simulation service will reduce prototype production, development period and development costs. In addition, it will contribute to optimization of parts to realize high cost performance.
For more information regarding our magnetic simulation service, refer to “Introduction of Magnetic Simulation Service.” For usage inquiries, contact our sales representatives.

Features

Uses a thin (t0.80 mm max.) TSOT-23-3S or ultra-thin (t0.50 mm max.) HSNT-6(2025) package, contributing to the enhancement of the designs of devices
Contributes to accurate mechanism operation with high-accuracy magnetic characteristics (Refer to "Magnetic Characteristics" in the datasheet for details.)
Suitable for devices which require high quality due to the production system of this IC which certifies automotive application quality
Contributes to device safe design with a built-in reverse voltage protection circuit and output current limit circuit

Specifications

Pole detection: Unipolar detection
Output logic^*1: Active "L"
Active "H"
Output form^*1: Nch open-drain output
Nch driver + built-in pull-up resistor(1.2kΩ typ.)
Magnetic sensitivity^*1: Bop = 3.0 mT typ.
Bop = 6.0 mT typ.
Bop = 10.0 mT typ.
Bop = 15.0 mT typ.
Chopping frequency: fc = 500 kHz typ.
Output delay time: td = 8.0 μs typ.
Power supply voltage range^*2: Vdd = 2.7 V to 26.0 V
Built-in regulator
Built-in reverse voltage protection circuit
Built-in output current limit circuit
Operation temperature range: Ta = −40℃ to +150℃
Lead-free (Sn 100%), halogen-free
AEC-Q100 qualified^*3

*1. The option can be selected.
*2. V_DD = 2.7 V to 5.5 V when output form is Nch driver + built-in pull-up resistor (1.2 kΩ typ.)
*3. Contact our sales representatives for details.

Applications

Automobile equipment
Housing equipment
Industrial equipment

Parts List

U(Ux), S and G at the end of the product name of ABLIC Inc. were used to indicate different material specifications as “environmental code”,
however, these have now been unified into “lead-free and halogen-free” and are identical in terms of environmental quality.
Note: Lead-free plating other than 100% Sn is applied to some limited old products, therefore, please contact our sales representatives for details.
These descriptions may be different from the actual product name and parameter.
Please confirm the product name and specifications with the data sheet again.
The information herein is subject to change without notice.

Automotive, 150°C Operation, High-Withstand Voltage, High-Speed, Unipolar Detection Type Hall Effect Switch IC S-57GS/GN S Series
