Automotive, 125°C Operation, 36 V, Voltage Detector with Fast Detection Response, SENSE Pin Reverse Connection Protection, Delay Function (External Delay Time Setting) S-19114xxxA Series

The industry's Fastest* Detection Response Improves the safety S-19114xxxA Series

This IC, developed using CMOS technology, is a high-accuracy voltage detector. The detection voltage and release voltage are fixed internally with an accuracy of ±1.5%.
Since the detection response time is as fast as 10 μs max., voltage abnormalities can be detected and notified quickly. Apart from the power supply pin, the detection voltage input pin (SENSE pin) is also prepared, so the output is stable even if the SENSE pin voltage (VSENSE) falls to 0 V. The SENSE pin also has a built-in reverse connection protection circuit that reduces current in the SENSE pin during a reverse connection.
The release signal can be delayed by setting a capacitor externally, and the release delay time accuracy is ±20% (CD = 3.3 nF). The output form is Nch open-drain output.

FIT rate calculation
ABLIC Inc. offers FIT rate calculated based on actual customer usage conditions in order to support customer functional safety design.
For more information regarding our FIT rate calculation, contact our sales representatives.

Caution: This product can be used in vehicle equipment and in-vehicle equipment. Before using the product for these purposes, it is imperative to contact our sales representatives.


Detection voltage
4.0 V to 12.0 V (0.05 V step)
Detection voltage accuracy
Hysteresis width selectable from "Available" / "Unavailable"
"Available": 2.0%, 5.0%, 10.0%
"Unavailable": 0%
Detection response time
10 μs max. (S-19114 Series L / M / N / R type)
25 μs max. (S-19114 Series P / Q / S / T type)
Release delay time
10 ms typ. (CD = 3.3 nF)
Release delay time accuracy
±20% (CD = 3.3 nF)
Current consumption
2.0 μA typ.
Operation voltage range
3.0 V to 36.0 V
Output form
Nch open-drain output
Built-in reverse connection protection circuit
Reduces current in the SENSE pin during a reverse connection.
Operation temperature range
Ta = −40°C to +125°C
Lead-free (Sn 100%), halogen-free
Withstand 45 V load dump
AEC-Q100 qualified*1

*1. Contact our sales representatives for details.


  • Automotive battery voltage detection
  • For automotive use (engine, transmission, suspension, ABS, related-devices for EV / HEV / PHEV, etc.)

Parts List

  • U(Ux), S and G at the end of the product name of ABLIC Inc. were used to indicate different material specifications as “environmental code”,
    however, these have now been unified into “lead-free and halogen-free” and are identical in terms of environmental quality.
  • Note: Lead-free plating other than 100% Sn is applied to some limited old products, therefore, please contact our sales representatives for details.
  • These descriptions may be different from the actual product name and parameter.
    Please confirm the product name and specifications with the data sheet again.
  • The information herein is subject to change without notice.
