Automotive, 150°C Operation, High-Withstand Voltage, High-Speed, Bipolar Hall Effect Latch IC S-57RB S Series

Hall effect ic for automotive

This IC, developed by CMOS technology, is a high-accuracy Hall effect latch IC that operates with high temperature and high-withstand voltage.
The output voltage level changes when this IC detects the intensity level of magnetic flux density and a polarity change. Using this IC with a magnet makes it possible to detect the rotation status in various devices.

Magnetic simulation service
ABLIC Inc. offers a “magnetic simulation service” that provides the ideal combination of magnets and our magnetic sensor ICs for customer systems. Our magnetic simulation service will reduce prototype production, development period and development costs. In addition, it will contribute to optimization of parts to realize high cost performance.
For more information regarding our magnetic simulation service, refer to “Introduction of Magnetic Simulation Service.” For usage inquiries, contact our sales representatives.

FIT rate calculation
ABLIC Inc. offers FIT rate calculated based on actual customer usage conditions in order to support customer functional safety design.
For more information regarding our FIT rate calculation, contact our sales representatives.

Caution: This product can be used in vehicle equipment and in-vehicle equipment. Before using the product for these purposes, it is imperative to contact our sales representatives.

Features

  • Uses a thin (t0.80 mm max.) TSOT-23-3S or ultra-thin (t0.50 mm max.) HSNT-6(2025) package, allowing for device miniaturization
  • Contributes to reduction of mechanism operation dispersion with high-accuracy magnetic characteristics (Typ. value ± 1.0 mT) (Refer to "Magnetic Characteristics" in the datasheet for details.)
  • Our production system certifies automotive application quality, which allows for use in devices which require high quality
  • Contributes to device safe design with a built-in reverse voltage protection circuit and output current limit circuit

Specifications

Pole detection
Bipolar latch
Output logic*1
Vout = "L" at S pole detection
Vout = "H" at S pole detection
Output form*1
Nch open-drain output
Nch driver + built-in pull-up resistor(1.2kΩ typ.)
Magnetic sensitivity*1
Bop = 0.5 mT typ.
Bop = 2.2 mT typ.
Bop = 3.0 mT typ.
Bop = 6.0 mT typ.
Bop = 10.0 mT typ.
Chopping frequency
fc = 500 kHz typ.
Output delay time
td = 8.0 μs typ.
Power supply voltage range*2
Vdd = 2.7 V to 26.0 V
Built-in regulator
Built-in reverse voltage protection circuit
Built-in output current limit circuit
Operation temperature range
Ta = −40℃ to +150℃
Lead-free (Sn 100%), halogen-free
AEC-Q100 qualified*3

*1. The option can be selected.
*2. VDD = 2.7 V to 5.5 V when output form is Nch driver + built-in pull-up resistor (1.2 kΩ typ.)
*3. Contact our sales representatives for details.

Applications

  • DC brushless motor for automotive applications
  • Automobile equipment
  • Housing equipment
  • Industrial equipment

Parts List

  • U(Ux), S and G at the end of the product name of ABLIC Inc. were used to indicate different material specifications as “environmental code”,
    however, these have now been unified into “lead-free and halogen-free” and are identical in terms of environmental quality.
  • Note: Lead-free plating other than 100% Sn is applied to some limited old products, therefore, please contact our sales representatives for details.
  • These descriptions may be different from the actual product name and parameter.
    Please confirm the product name and specifications with the data sheet again.
  • The information herein is subject to change without notice.
