エイブリックのリニアレギュレータ（LDOレギュレータ）は、超低消費電流、高耐圧・広動作電圧、超小型パッケージ、高リップル除去率などを特長とし、電源回路の低消費電力化、安定動作、高信頼性に貢献します。ソフトスタート回路、突入電流制限回路、放電シャント機能、出力電圧外部設定、出力キャパシタレス、電源分圧出力など、豊富なラインナップでお客さまのニーズにお応えします。
| シリーズ名 (製品概要) | データシート | Webshop | 出力電流 （mA） | 分類 | VIN min (V) | VIN max (V) | VOUT min (V) | VOUT max (V) | 精度 ±(%) *全温度 | 消費電流 (μA) | RR @1kHz (dB) | Vdrop (V) | Cout (μF) | 特長, 付加機能* * ICL 突入電流制御, DS 放電ｼｬﾝﾄ, TS サーマルシャットダウン | パッケージ |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| シリーズ名 | |||||||||||||||
| S-812C | chip1stop CoreStaFF Digi-Key MOUSER | 75 | Linear | - | 16 | 2.0 | 6.0 | 2.0 | 1 | - | 0.23 | - | 低出力電流タイプ, 16V入力 | SOT-23-5, SOT-89-3, SOT-89-5, SNT-6A(H), TO-92, WLP-4R | |
| S-817 | chip1stop CoreStaFF Digi-Key MOUSER | 75 | Linear | - | 10 | 1.1 | 6.0 | 2.0 | 1.2 | - | 0.25 | 0.1 | 低出力電流タイプ | SOT-23-5, SOT-89-3, SC-82AB, SNT-4A, TO-92 | |
| S-816 | chip1stop CoreStaFF Digi-Key MOUSER | 1000 | Linear | 2.5 | 16 | 2.5 | 6.0 | 2.0 | 30 | - | 0.1 | 4.7 | トランジスタ外付け | SOT-23-5 | |
| S-1317 | chip1stop CoreStaFF Digi-Key MOUSER | 100 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 0.35 | - | 0.02 | 1.0 | 超低消費電流、過電流保護 | SOT-23-5, HSNT-4(1010) | |
| S-1318 | chip1stop CoreStaFF Digi-Key MOUSER | 100 | LDO | 1.7 | 5.5 | 1.2 | 3.3 | 1.0 | 0.095 | - | 0.045 | 1.0 | 超低消費電流(動作時&パワーオフ時)、過電流保護 | SOT-23-5, HSNT-4(1010) | |
| S-1112 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 50 | 80 | 0.19 | 0.47 | 高リップル除去率の従来品 | SOT-23-5, SNT-6A(H) | |
| S-1122 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 50 | 80 | 0.19 | 0.47 | 高リップル除去率の従来品 | SOT-23-5 | |
| S-1167 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 9 | 70 | 0.15 | 1.0 | 低消費電流で高リップル除去率 | SOT-23-5, SNT-6A(H) | |
| S-1312 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 20 | 75 | 0.16 | 0.22 | 0.8mm超小型, TS*, DS* | SOT-23-5, HSNT-4(0808), HSNT-4(1010) | |
| S-1312xxxH | 150 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 20 | 75 | 0.16 | 0.22 | 105℃動作, TS*, DS* | SOT-23-5, HSNT-4(1010) | ||
| S-1323 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 70 | 70 | 0.5 | 1.0 | 従来品 | SC-82AB, SNT-4A | |
| S-1335 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 1.5 | 5.5 | 1.0 | 3.6 | 1.0 | 36 | 80 | 0.07 | 1.0 | 高リップル除去率, ソフトスタート, DS* | SOT-23-5, SC-82AB, HSNT-4 (1010) | |
| S-13R1 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 5.5 | 1.2 | 4.0 | 1.0 | 5 | 70 | 0.15 | 1.0 | 逆流電流防止, TS*, DS* | SOT-23-5, SC-82AB, HSNT-4(1010) | |
| S-T111 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 50 | 80 | 0.19 | 0.1 | TK111相当 | SOT-23-5 | |
| S-1200 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 10 | 1.5 | 5.5 | 1.0 | 18 | 70 | 0.14 | 0.1 | 10V入力対応 | SOT-23-5, SNT-6A(H), HSNT-6A | |
| S-L2980 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | LDO | 2.0 | 10 | 1.5 | 6.0 | 2.0 | 90 | 70 | 0.12 | 1.0 | LP2980相当 | SOT-23-5 | |
| S-1222B/D | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 3.0 | 28 | 2.3 | 12.0 | 1.0 | 6.5 | - | 0.35 | 1.0 | 低背0.33mm(max.), 低消費, TS*, DS* | TO-252-5S(A), HSOP-8A, HSOP-6, SOT-89-5, HTMSOP-8, SOT-23-5, DFN-6(1518)A | |
| S-1313 | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 0.9 | - | 0.16 | 0.1 | 0.8mm超小型, 超低消費, TS*, DS* | SOT-23-5, SC-82AB, HSNT-4(0808), HSNT-4(1010) | |
| S-1313xxxH | 200 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 0.9 | - | 0.16 | 0.1 | 105℃動作, 0.8mm超小型, 超低消費, TS*, DS* | SOT-23-5, SC-82AB, HSNT-4(0808), HSNT-4(1010) | ||
| S-1315 | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 1.4 | 5.5 | 1.0 | 4.2 | 1.0 | 7 | 65 | 0.22 | 0 | 出力キャパシタレス, DS* | SOT-23-5, HSNT-6(1212) | |
| S-1324 | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 7 | 65 | 0.17 | 1.0 | 低消費, 低ノイズ17μVrms | SOT-23-5, SC-82AB, HSNT-4(1010) | |
| S-1206 | chip1stop CoreStaFF Digi-Key MOUSER | 250 | LDO | 1.7 | 6.5 | 1.2 | 5.2 | 1.0 | 1 | - | 0.15 | 0.1 | 超低消費電流 | SOT-23-3, SOT-89-3, SNT-6A(H) | |
| S-1132 | chip1stop CoreStaFF Digi-Key MOUSER | 300 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 20 | 70 | 0.13 | 0.1 | 0.1uFコンデンサ使用可能 | SOT-23-5, SOT-89-5, SNT-6A(H) | |
| S-1133 | chip1stop CoreStaFF Digi-Key MOUSER | 300 | LDO | 2.0 | 10 | 1.2 | 8.2 | 1.0 | 60 | 70 | 0.13 | 1.0 | 出力電圧外部設定可能, TS* | SOT-89-5, SNT-8A | |
| S-1333 | chip1stop CoreStaFF Digi-Key MOUSER | 300 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 25 | 75 | 0.14 | 1.0 | 0.8mm超小型, TS*, DS* | SOT-23-5, HSNT-4(0808), HSNT-4(1010) | |
| S-1170 | chip1stop CoreStaFF Digi-Key MOUSER | 800 | LDO | 2.0 | 6.5 | 1.5 | 5.5 | 1.0 | 80 | 70 | 0.12 | 4.7 | TS* | SOT-89-5, 6-Pin_HSON(A) | |
| S-13A1 | chip1stop CoreStaFF Digi-Key MOUSER | 1000 | LDO | 1.5 | 5.5 | 1.0 | 5.0 | 1.0 | 60 | 70 | 0.07 | 2.2 | ICL*, TS*, DS*, Vout外部設定可能 | HSOP-8A, HSOP-6, SOT-89-5, HSNT-6A | |
| S-818 | chip1stop CoreStaFF Digi-Key MOUSER | 300 | LDO | - | 10 | 2.0 | 6.0 | 2.0 | 30 | - | 0.3 | 2.0 | SOT-23-5, SOT-89-5 | ||
| S-1701 | chip1stop CoreStaFF Digi-Key MOUSER | 400 | LDO+VD | 2.0 | 6.5 | 1.5 | 5.0 | 1.0 | 85 | 70 | 0.14 | 1.0 | LDO1回路+ディテクタ1回路 | SOT-23-5, SOT-89-5 | |
| S-1721 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | 2 LDOs | 1.7 | 6.5 | 1.2 | 5.0 | 1.0 | 25 | 80 | 0.13 | 1.0 | LDO2回路, 高リップル除去率 | SOT-23-6, SNT-6A | |
| S-1740/1741 | chip1stop CoreStaFF Digi-Key MOUSER | 100 | LDO | 1.5 | 5.5 | 1.0 | 3.5 | 1.0 | 0.5 | - | 0.02 | 1.0 | 電源分圧出力機能 | SOT-23-5, HSNT-6(1212), HSNT-4(1010) | |
| S-13D1 | chip1stop CoreStaFF Digi-Key MOUSER | 150 | 2 LDOs | 1.5 | 5.5 | 1.0 | 3.6 | 1.0 | 39 | 70 | 0.08 | 0.22 | LDO2回路, ディレイ機能, TS*, DS* | SOT-23-6, HSNT-6(1212) | |
| S-87x | chip1stop CoreStaFF Digi-Key MOUSER | 50 | VR+VD | - | 24 | 2.5 | 5.8 | 2.4 | 3 | - | 0.45 | - | 24V入力対応、VR+ディテクタ | SOT-89-5 | |
| S-1212B/D | chip1stop CoreStaFF Digi-Key MOUSER | 250 | LDO | 3.0 | 36 | 2.5 | 16 | 2.0 | 6.5 | 40 | 0.35 | 1.0 | 36V高入力、105℃動作, TS*, DS* | TO-252-5S(A), SOT-23-5, SOT-89-5, HSOP-6, HSOP-8A, HTMSOP-8 | |
| S-1213 | chip1stop CoreStaFF Digi-Key MOUSER | 500 | LDO | 2.8 | 36 | 1.8 | 30 | 1.0 | 5.0 | - | 0.13 | 1.0 | 36V高入力、105℃動作, TS*, DS*, Vout外部設定可能 | TO-252-5S(A), HSOP-8A | |
| S-1214 | chip1stop CoreStaFF Digi-Key MOUSER | 1000 | LDO | 2.8 | 36 | 1.8 | 30 | 1.0 | 5.0 | - | 0.13 | 1.0 | 36V高入力、105℃動作, TS*, DS*, Vout外部設定可能 | TO-252-5S(A), HSOP-8A | |
| S-1142A/B | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 3.0 | 50 | 2.0 | 15 | 1.0 | 4 | 50 | 0.35 | 0.1 | 50V高入力対応（低消費電流）, TS* | HSOP-6 | |
| S-1142C/D | chip1stop CoreStaFF Digi-Key MOUSER | 200 | LDO | 3.0 | 50 | 2.0 | 15 | 1.0 | 4 | 50 | 0.35 | 0.1 | 50V高入力対応（低消費電流）, TS* | HSOP-6 | |
| S-8424A | chip1stop CoreStaFF Digi-Key MOUSER | バッテリバックアップ切替 | 8-Pin TSSOP |
If you can not find the product, please click here or contact our sales representatives.
