Precise Reference Elevates Sensor Performance
The S-19760/1 Series achieves the industry’s highest* output voltage accuracy of ±0.1% and the industry’s lowest* output voltage temperature coefficient of 20ppm/°C. This superior temperature characteristic allows the S-19760/1 Series to supply a high-precision, stable reference voltage even in harsh environments.
Learn more
What is a Voltage Reference?
A voltage reference is a linear regulator capable of maintaining a highly stable output voltage. Voltage references are widely used as the reference voltage sources for components requiring high-precision, such as A/D converters (ADC), comparators, and sensors.
Learn more
[Application]ICs ideal for ADAS Domain Controllers
ABLIC provides a comprehensive product lineup, including shunt voltage references that generate the high-precision reference voltages required for sensor reading, watchdog timers that monitor MCUs with built-in VD, and connection diagnosis ICs for supplying power to GNSS antenna amplifiers.
Learn more
Accelerating Advancement of Industrial Equipment
The S-8564/5 Series delivers a 1A output, enabling devices to achieve greater functionality and higher performance. With a 36V input (absolute maximum rating of 45V) and a synchronous rectification switching regulator (DC-DC converter), it features the industry’s smallest* HSNT-8(2030) package (3.0 × 2.0 × t0.5 (max.) mm).
Learn more
Further Miniaturizing Camera Modules
The S-19560B Series is a compact 3-channel PMIC that integrates two buck DC-DC converters and one LDO regulator in a space-saving HSNT-8(2030) package (3.0 × 2.0 × t0.5mm).
Learn more
Design Rotation Detection with Greater Freedom for Automotive Motors
The S-57W1/W2 S Series integrates a Hall element capable of detecting magnetic flux density in two different directions on a single chip, allowing it to automatically detect magnetic flux density with a 90° phase difference. The S-57W1/W2 S Series offers a high-sensitivity product with 0.8mT (typ.), enabling reliable detection of weak magnetic flux density. This makes it ideal for motor applications using multi-pole ring magnets with a large number of poles.
Learn more
S-19761
Automotive, 125°C Operation, ±0.1%, 20 ppm/°C, Low noise, High-Precision Shunt Voltage Reference S-19761 Series
S-19760
Automotive, 125°C Operation, ±0.1%, 20 ppm/°C, Low noise, High-Precision Shunt Voltage Reference S-19760 Series
S-19231
车载用、工作温度125°C、66 V输入、200 mA的电压稳压器 S-19231系列 VOUT expansion (Internally/Externally set)
S-19230
车载用、工作温度125°C、66 V输入、100 mA的电压稳压器 S-19230系列 VOUT expansion (Internally/Externally set)
S-1231
工作温度105°C、66 V输入、200 mA的电压稳压器 S-1231系列 VOUT expansion (Internally set)
关于艾普凌科有限公司
艾普凌科有限公司于1968年以开发全球第一款量产石英表的CMOS IC为基础，开展了模拟半导体业务。此后，我们也开始为各式各样的家用电器，手机终端，车载设备及医疗器械提供小型、低功耗、高精度的模拟半导体产品。 2020年4月，成为了美蓓亚三美集团的一员，目标以“通过‘Small Smart Simple’的模拟半导体解决方案，为客户带来感动”为愿景，为繁荣社会做出贡献。
