一般用途 | 車載用
車載用スイッチングレギュレータ (DC-DCコンバータ) は、レギュレータ (安定化電源) の一種で、入力された直流 (DC) 電圧を所望の直流 (DC) 電圧に変換します。車載電子機器においてバッテリなどから供給される電源電圧から、後続システムに適した電圧へ変換する役割を担います。
エイブリックの車載用スイッチングレギュレータは、降圧 (buck) および昇圧 (boost) タイプを提供しています。1.6×1.6mmや2.0×3.0mmの小型パッケージ、36V入力電圧/45V定格の高耐圧品のほか、過電流保護、短絡保護、サーマルシャットダウン、スペクトラム拡散型発振回路、パワーグッド、STATUS端子など多彩な機能を備えています。
また、エイブリックの車載用スイッチングレギュレータはAEC-Q100対応、およびPPAP (生産部品承認プロセス) に対応可能です。これにより、高い品質と信頼性を確保し、EPSモータやトラクション・インバータなどの重要保安部品にも採用されています。FIT値の提供により、お客様の車載アプリケーション設計をサポートします。
ピックアップ製品
新製品
アプリケーション
製品ラインナップ
- Linear Regulators (LDO Regulators) (125°C)
- Linear Regulators (LDO Regulators) (105°C)
- Voltage Trackers (125°C)
- Voltage Detectors (Battery Monitoring & Reset ICs) (150°C)
- Voltage Detectors (Battery Monitoring & Reset ICs) (125°C)
- Voltage Detectors (Battery Monitoring & Reset ICs) (105°C)
- Watchdog Timers
- Switching Regulators (DC-DC Converters)
- Connection Diagnosis ICs
- Lithium-ion Battery Protection ICs / EDLC Protection ICs
Linear Regulators (LDO Regulators) (125°C)
10V 20V 30V 40V 50V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- ISS (µA)
- 1000
- S-19214 Features: Low current consumption, ON/OFF circuit, Output voltage externally set product is selectable
Package: TO-252-5S(A), HSOP-8A - 1.8 to 30
- 5.0
- S-19244 Features: Soft-start function, Output voltage externally set product is selectable
Package: TO-252-5S(A), HSOP-8A, HSOP-6, HSNT-8(2030) - 1.0 to 9.0
- 120
- S-19259 Features: Output voltage externally set product is selectable
Package: TO-252-5S(A), HSOP-8A, HSNT-8(2030) - 0.9 to 5.0
- 60
- S-19214 Features: Low current consumption, ON/OFF circuit, Output voltage externally set product is selectable
- 600
- S-19701 Features: Current monitoring function, High side switch is possible, Reverse current protection function
Package: HSOP-8A - 3.3 to 20
- 80
- S-19701 Features: Current monitoring function, High side switch is possible, Reverse current protection function
- 500
- S-19213 Features: Low current consumption, ON/OFF circuit, Output voltage externally set product is selectable
Package: TO-252-5S(A), HSOP-8A - 1.8 to 30
- 5.0
- S-19218 Features: Fast transient response
Package: TO-252-5S(A), HSOP-8A - 2.5 to 30
- 30
- S-19318 Features: Low current consumption, High power dissipation
Package: HSOP-8A, TO-252-9S - 3.3, 5.0
- 3.0
- S-19506/7 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19509 Features: High-withstand voltage LDO + Reset function + WDT, Time-out mode, Enable pin
Package: HSOP-8A, TO-252-9S, HTSSOP-16 - 3.3 to 5.0
- 3.2
- S-19516/7 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19519 Features: High-withstand voltage LDO + Reset function + WDT, Window mode, Enable pin
Package: HSOP-8A, TO-252-9S, HTSSOP-16 - 3.3 to 5.0
- 3.2
- S-19243 Features: Soft-start function, Output voltage externally set product is selectable
Package: TO-252-5S(A), HSOP-8A, HSOP-6, SOT-89-5, HSNT-8(2030) - 0.9 to 9.0
- 120
- S-19213 Features: Low current consumption, ON/OFF circuit, Output voltage externally set product is selectable
- 400
- S-19312 Features: High-withstand voltage LDO + Reset
Package: HSOP-8A, TO-252-5S(A) - 3.0 to 5.3
- 60
- S-19502/3 Features: High-withstand voltage LDO + Reset function + WDT
Package: HSOP-8A, TO-252-9S - 3.0 to 5.3
- 60
- S-19700 Features: Current monitoring function, High side switch is possible, Reverse current protection function
Package: HSOP-8A - 3.3 to 20
- 80
- S-19312 Features: High-withstand voltage LDO + Reset
- 300
- 250
- S-19212 Features: Low current consumption, ON/OFF circuit
Package: TO-252-5S(A), HSOP-8A, HSOP-6, SOT-89-5, SOT-23-5, HTMSOP-8 - 2.5 to 16
- 6.5
- S-19317 Features: Low current consumption, High power dissipation
Package: HSOP-8A, TO-252-9S - 3.3, 5.0
- 3.0
- S-19504/5 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19514/5 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19518 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode, Enable pin
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.2
- S-19721 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection, Anomaly notification
Package: TO-252-9S, HSOP-8A, HSNT-8(2030) - ―
- 40
- S-19212 Features: Low current consumption, ON/OFF circuit
- 200
- S-1142 Features: Low current consumption, ON/OFF circuit
Package: HSOP-6 - 2.0 to 12
- 4.0
- S-19200 Features: Low current consumption, ON/OFF circuit
Package: TO-252-5S(A) - 2.0 to 15
- 4.0
- S-19311 Features: High-withstand voltage LDO + Reset
Package: HSOP-8A, TO-252-5S(A) - 3.0 to 5.3
- 60
- S-19500/1 Features: High-withstand voltage LDO + Reset function + WDT
Package: HSOP-8A - 3.0 to 5.3
- 60
- S-1142 Features: Low current consumption, ON/OFF circuit
- 50
- S-19720 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection
Package: SOT-23-5, HSNT-6(2025) - ―
- 30
- S-19720 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection
- 40
- S-19310 Features: High-withstand voltage LDO + Reset, Low current consumption
Package: HTMSOP-8, SOT-23-5, SOT-89-5 - 2.9 to 5.3
- 2.2
- S-19315 Features: High-withstand voltage LDO + High-speed detection reset function, Low current consumption, SENSE input
Package: HTMSOP-8, SOT-23-5, SOT-89-5 - 1.0 to 5.3
- 2.0
- S-19316 Features: High-withstand voltage LDO + High-speed detection reset function, Low current consumption, Input monitoring
Package: HTMSOP-8, SOT-23-5, SOT-89-5 - 1.0 to 5.3
- 2.0
- S-19310 Features: High-withstand voltage LDO + Reset, Low current consumption
10V 20V 30V 40V 50V
Linear Regulators (LDO Regulators) (105°C)
10V 20V 30V 40V 50V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- ISS (µA)
- 2000
- S-19246 Features: High output current, Soft-start function
Package: TO-252-5S(A) - 1.0 to 6.0
- 120
- S-19246 Features: High output current, Soft-start function
- 1000
- 500
- 250
- S-19212 Features: Low current consumption, ON/OFF circuit
Package: TO-252-5S(A), HSOP-8A, HSOP-6, SOT-89-5, SOT-23-5, HTMSOP-8 - 2.5 to 16
- 6.5
- S-19212 Features: Low current consumption, ON/OFF circuit
- 200
- 150
10V 20V 30V 40V 50V
Voltage Trackers (125°C)
ΔVOUT: Offset voltage
ISS1: Current consumption during operation ISS2: Current consumption during power-off
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- ΔVOUT (mV)
- ISS1 (µA)
- ISS2 (µA)
- 250
- S-19721 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection, Anomaly notification
Package: TO-252-9S, HSOP-8A, HSNT-8(2030) - ±4.5
- 40
- 3.7
- S-19721 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection, Anomaly notification
- 50
- S-19720 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection
Package: SOT-23-5, HSNT-6(2025) - ±5
- 30
- 4.0
- S-19720 Features: Low offset voltage, Low current consumption during power-off, Reverse current protection
10V 20V 30V 40V
Voltage Detectors (Battery Monitoring & Reset ICs) (150°C)
[Single detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-19113 Features: AEC-Q100 Grade 0, SENSE detection, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - 4.0 to 10
- ―
- 0.6
- S-19115 Features: AEC-Q100 Grade 0, SENSE detection, SENSE pin reverse connection protection, Overvoltage detection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - ―
- 16 to 18
- 0.6
- S-19117/9 Features: AEC-Q100 Grade 0, SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- ―
- 0.75
- S-19113 Features: AEC-Q100 Grade 0, SENSE detection, SENSE pin reverse connection protection
10V 20V 30V 40V
[Window detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-191E Features: AEC-Q100 Grade 0, SENSE detection, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191L/N Features: AEC-Q100 Grade 0, SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191E Features: AEC-Q100 Grade 0, SENSE detection, SENSE pin reverse connection protection, Window
10V 20V 30V 40V
Voltage Detectors (Battery Monitoring & Reset ICs) (125°C)
[Single detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-19110E to H Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 5.0 to 10
- ―
- 0.55
- S-19110N to R Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 3.0 to 4.95
- ―
- 0.55
- S-19113 Features: SENSE detection, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - 4.0 to 10
- ―
- 0.6
- S-19114 Features: SENSE detection, SENSE pin reverse connection protection, fast detection response
Package: HSNT-6(2025), SOT-23-5 - 4.0 to 12
- ―
- 2.0
- S-19115 Features: SENSE detection, SENSE pin reverse connection protection, Overvoltage detection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - ―
- 12.2 to 18
- 0.6
- S-19116 Features: SENSE detection, Fast detection response, SENSE pin reverse connection protection, Overvoltage detection
Package: HSNT-6(2025), SOT-23-5 - ―
- 8.0 to 24
- 2.0
- S-19117/9 Features: SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- ―
- 0.75
- S-19122 Features: SENSE detection, Fast detection response, Manual reset
Package: SOT-23-6, HSNT-8(1616)B - 0.6 to 4.9
- ―
- 1.2
- S-19110E to H Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
- VDD
detection- S-19110A to D Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 5.0 to 10
- ―
- 0.6
- S-19110J to M Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 3.6 to 4.95
- ―
- 0.6
- S-19100 Features: Delay function
Package: SC-82AB, SOT-23-5 - 1.2 to 4.6
- ―
- 0.27
- S-19101 Features: Delay function
Package: SC-82AB, SOT-23-5 - 1.2 to 4.6
- ―
- 0.27
- S-19400/1 Features: Reset function + WDT, Window mode is selectable
Package: TMSOP-8, HSNT-8(2030) - 2.0 to 5.0
- ―
- 3.8
- S-19405 Features: Reset function + WDT, Time-out mode
Package: TMSOP-8, HSNT-8(2030) - 2.0 to 5.0
- ―
- 3.8
- S-19110A to D Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
10V 20V 30V 40V
[Window detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-191E Features: SENSE detection, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191L/N Features: SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191A Features: SENSE detection, Fast detection response, Manual reset, Window
Package: SOT-23-6, HSNT-8(1616)B - 0.6 to 4.9
- 0.7 to 5.5
- 1.5
- S-191B Features: SENSE detection, Fast detection response, Window
Package: SOT-23-6, HSNT-8(1616)B - 0.6 to 4.9
- 0.7 to 5.5
- 1.5
- S-191E Features: SENSE detection, SENSE pin reverse connection protection, Window
10V 20V 30V 40V
Voltage Detectors (Battery Monitoring & Reset ICs) (105°C)
[Single detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-19110E to H Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 5.0 to 10
- ―
- 0.55
- S-19110N to R Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 3.0 to 4.95
- ―
- 0.55
- S-19113 Features: SENSE detection, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - 4.0 to 10
- ―
- 0.6
- S-19115 Features: SENSE detection, SENSE pin reverse connection protection, Overvoltage detection
Package: HTMSOP-8, HSNT-8(2030), SOT-23-5 - ―
- 16 to 18
- 0.6
- S-19117/9 Features: SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- ―
- 0.75
- S-19102/8 Features: SENSE detection
Package: SOT-23-5 - 1.0 to 5.0
- ―
- 0.5
- S-19103/9 Features: SENSE detection
Package: SOT-23-5 - 1.0 to 5.0
- ―
- 0.5
- S-19104/6 Features: SENSE detection, Delay function
Package: SOT-23-5 - 1.0 to 5.0
- ―
- 0.5
- S-19105/7 Features: SENSE detection, Delay function
Package: SOT-23-5 - 1.0 to 5.0
- ―
- 0.5
- S-19110E to H Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
- VDD
detection- S-19110A to D Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 5.0 to 10
- ―
- 0.6
- S-19110J to M Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
Package: SOT-23-6 - 3.6 to 4.95
- ―
- 0.6
- S-19100 Features: Delay function
Package: SC-82AB, SOT-23-5, SNT-4A - 1.2 to 4.6
- ―
- 0.27
- S-19101 Features: Delay function
Package: SC-82AB, SOT-23-5 - 1.2 to 4.6
- ―
- 0.27
- S-19110A to D Features: Hysteresis width is selectable, SENSE / VDD detection is selectable, Delay function
10V 20V 30V 40V
[Window detection]
10V 20V 30V 40V
- Type
- Product / VDD (V)
- VUVDET (V)
- VOVDET (V)
- ISS (µA)
- SENSE
detection- S-191E Features: SENSE detection, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191L/N Features: SENSE detection, Supply voltage divided output, SENSE pin reverse connection protection, Window
Package: HTMSOP-8, HSNT-8(2030) - 4.0 to 10
- 16 to 18
- 0.9
- S-191E Features: SENSE detection, SENSE pin reverse connection protection, Window
10V 20V 30V 40V
Watchdog Timers (125°C)
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- ISS (µA)
- 500
- S-19506/7 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19509 Features: High-withstand voltage LDO + Reset function + WDT, Time-out mode, Enable pin
Package: HSOP-8A, TO-252-9S, HTSSOP-16 - 3.3 to 5.0
- 3.2
- S-19516/7 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19519 Features: High-withstand voltage LDO + Reset function + WDT, Window mode, Enable pin
Package: HSOP-8A, TO-252-9S, HTSSOP-16 - 3.3 to 5.0
- 3.2
- S-19506/7 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
- 400
- S-19502/3 Features: High-withstand voltage LDO + Reset function + WDT
Package: HSOP-8A, TO-252-9S - 3.0 to 5.3
- 60
- S-19502/3 Features: High-withstand voltage LDO + Reset function + WDT
- 250
- S-19504/5 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19514/5 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.0
- S-19518 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Window mode, Enable pin
Package: HSOP-8A, TO-252-9S - 3.3 to 5.0
- 3.2
- S-19504/5 Features: High-withstand voltage LDO + Reset function + WDT, Low current consumption, Time-out mode
- 200
- S-19500/1 Features: High-withstand voltage LDO + Reset function + WDT
Package: HSOP-8A - 3.0 to 5.3
- 60
- S-19500/1 Features: High-withstand voltage LDO + Reset function + WDT
- ―
10V 20V 30V 40V
Switching Regulators (DC-DC Converters) (125°C)
[Step-down]
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- Freq. (kHz)
- 1000
- S-19914/5 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 2.5 to 12
- 2200
- S-19904/5 A/B Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 2.5 to 12
- 2200
- S-19944/5 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 1.0 to 12
- 2200
- S-19934/5 A/B Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 1.0 to 12
- 2200
- S-19954/5 Features: Power Good, Synchronous, Small packages
Package: HSNT-8(1616)B, HTMSOP-8 - 0.8 to 3.3
- 2250
- S-19914/5 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
- 600
- S-19912/3 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 2.5 to 12
- 2200
- S-19902/3 A/B Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030), HSNT-6(2025) - 2.5 to 12
- 2200
- S-19902/3 C/D Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030), HSNT-6(2025) - 2.5 to 12
- 400
- S-19942/3 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030) - 1.0 to 12
- 2200
- S-19932/3 A/B Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030), HSNT-6(2025) - 1.0 to 12
- 2200
- S-19932/3 C/D Features: Synchronous, Small packages
Package: HTMSOP-8, HSNT-8(2030), HSNT-6(2025) - 2.5 to 12
- 400
- S-19952/3 Features: Power Good, Synchronous, Small packages
HSNT-8(1616)B, HTMSOP-8 - 0.8 to 3.3
- 2250
- S-19912/3 A/B Features: Spread spectrum clock generation circuit, Synchronous, Small packages
10V 20V 30V 40V
[Step-up]
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- Freq. (kHz)
- –
- S-19980 STEP-UP / FLYBACK SWITCHING REGULATOR CONTROLLER
Features: Wide input operating range of 3V to 36 V, Small package
Package: HSNT-8(2030), HTMSOP-8 - –
- 400, 2200
- S-19989 START-STOP STEP-UP SWITCHING REGULATOR CONTROLLER
Features: Wide input operating range of 3V to 36 V, Small package
Package: HSNT-8(2030), HTMSOP-8 - 6.8, 8.5
- 400, 2200
- S-19990 STEP-UP / FLYBACK SWITCHING REGULATOR CONTROLLER
Features: Spread spectrum clock generation circuit, Wide input operating range of 3V to 36 V, Small package
Package: HSNT-8(2030), HTMSOP-8 - –
- 400, 2200
- S-19999 START-STOP STEP-UP SWITCHING REGULATOR CONTROLLER
Features: Spread spectrum clock generation circuit, Wide input operating range of 3V to 36 V, Small package
Package: HSNT-8(2030), HTMSOP-8 - 6.8, 8.5
- 400, 2200
- S-19980 STEP-UP / FLYBACK SWITCHING REGULATOR CONTROLLER
10V 20V 30V 40V
Connection Diagnosis ICs (125°C)
[LDO]
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- ISS (µA)
- 600
- S-19701 Features: Current monitoring function, High side switch is possible, Reverse current protection function
Package: HSOP-8A - 3.3 to 20
- 80
- S-19701 Features: Current monitoring function, High side switch is possible, Reverse current protection function
- 400
- S-19700 Features: Current monitoring function, High side switch is possible, Reverse current protection function
Package: HSOP-8A - 3.3 to 20
- 80
- S-19700 Features: Current monitoring function, High side switch is possible, Reverse current protection function
10V 20V 30V 40V
[High side switch]
10V 20V 30V 40V
- IOUT (mA)
- Product / VIN (V)
- VOUT (V)
- ISS (µA)
- 600
- S-19683B Features: Current monitoring function, Small package, Low current consumption
Package: HSNT-8(2030) - ―
- 55
- S-19683B Features: Current monitoring function, Small package, Low current consumption
- 300
- S-19682B Features: Current monitoring function, Small package, Low current consumption
Package: HSNT-8(2030) - ―
- 55
- S-19682B Features: Current monitoring function, Small package, Low current consumption
- 100
- S-19680 Features: Current monitoring function, Low cuurent consumption, 105°C operation
Package: TMSOP-8 - ―
- 12
- S-19680 Features: Current monitoring function, Low cuurent consumption, 105°C operation
10V 20V 30V 40V
[Voltage tracker]
Lithium-ion Battery Protection ICs / EDLC Protection ICs (125°C/105°C)
| Function | ||||||||
| Cell-balancing | S-19190 Package: SOT-23-6 | |||||||
| Overcharge detection | S-19161 Features: For 1-cell pack, SENSE resistor type available Package: SOT-23-6 |
S-19192 Features: Self-test function Package: HTSSOP-16 |
S-19193 Features: Cascade connection function Package: HTSSOP-16 |
|||||
| Overdischarge detection | ||||||||
| 1-cell | .... | 6-cell | 7-cell or more | Number of cells | ||||
